Soft Panel 400DW
CW+WW LED
Source：640W WW+CW LED
Output：49700 Lm
Beam angle：68°
Field angle：111°
CRI: 98
CT：3000 ~ 5700K
Automatic color correction system ensures stable and consistent color and color temperatur
Specification
OPTIC
Source：640W CW+WW LED
Output：49700 Lm
Beam angle：68°
Field angle：111°
CT：3000 ~ 5700K
CRI：98
Lifetime：50000 H
EFFECT
Strobe：1 ~ 25 Hz
Dimmer Curve：4 kinds
Automatic color correction system ensures stable and consistent color and color temperature
Manual dimming by potentiometer, quickselection of color temperature and colorsaturation selection
CONTROL & PROGRAM
Channel：1 / 2 / 8 CH
Protocal：DMX512, RDM
Data connector：3 PIN XLR（Optional：5 PIN XLR）
Display：OLED display
SOFTWARE
Via USB & DMX signal to update
Silent fan, intelligent speed regulation
Intelligent temperature protection to ensure LED service life
SUITABLE FOR THE VENUE
TV station studio, professional stage, interview with reporters, shooting film and television lights, conference halls, etc.
HOUSING
Aluminum alloy structure
Fan cooling（intelligent speed regulation）
OTHER
IP rating：IP30
Work environment：-40℃—45℃
Startup environment：-20℃—45℃
POWER CONSUMPTION
Voltage：AC 100V-240V 50/60HZ
Rated power：523W
SIZE & WEIGHT
Size：860 × 141 × 415 mm
N.W：15 kgs
Photometrics
Dimensions
