Source: 1400W CW LED
Beam angle：6～50°
CRI: 72 / 95 （Freedom to switch）
High Brightness Mode: 52000 Lm
High CRI Mode: 32000 Lm
Beams, Spot, Wash, Frame
Rotation gobo: Wheel 1 (6 + 1) Wheel 2 (6 + 1)
Color wheel：5 + 1 / CMY / CTO
Prism：4 prism+6 linear
Lightweight alloy shell, low overall weight
Source: 1400W CW LED
Beam angle： 6～50°
CRI: 72 / 95 （Freedom to switch）
High Brightness Mode: 52000 Lm
High CRI Mode: 32000 Lm
CT：6500 K
Lifetime: 20000 H
Strobe：1～25Hz
LED refresh rate：900Hz - 25KHz
Rotation gobo: Wheel 1 (6 + 1)
Wheel 2 (6 + 1)
Gobo: Ф30 mm, lmage: Ф 25 mm, thickness: 1.1mm
Color wheel：5+ 1
CMY / CTO
Prism：4 prism+6 linear
Frost: 2
Framing: With 4 blade, can achieve fast and smooth cutting. The framing direction and angle of each blade can be controlled separately, and the each brade can realize complete beam closing. The whole cutting module can be rotated by ±60°
Animation + With iris
Channel：38 / 54CH
Protocal：DMX512, RDM
Data connector：3 PIN XLR（Optional：5 PIN XLR）
Display: 2.8 inches touch screen, the operation panel has a rechargeable battery that allows you to access the menu to set the address code and make other settings without power on
Via USB & DMX signal to update
Static waterproof fan intelligent speed control
Intelligent temperature protection to ensure LED service life
Pan: 540° or 630° 8bit/16bit
Tilt: 270° 8bit/16bit
Aluminum alloy structure + plastic (VO)
Fan cooling
Resistant to salt corrosion
IP rating: IP65
Work environment: -40℃ ~ 45℃
Startup environment: -20℃ ~ 45℃
Voltage: AC 100V~240V 50/60Hz
Rated power：1800W
Power factor：0.99
Size：503 × 366 × 827 mm
N.W：52.8 kgs
Carton Size：975 × 635 × 535 mm
G.W：64.7 kgs
Flight Case：700 × 680 × 900 mm
G.W：103.8 kgs
