IP H2O 200

Source:  200W CW LED

Output:5760Lm

Field angle:25°/45°/55°

Color wheel:7+1

Create a rainbow flowing water effect

IP rating: IP65


Specification
OPTIC

Source: 200W CW LED

Output:5760 Lm

Field angle:25°/45°/55°(Optional)

Lifetime:20000 H

EFFECT

Strobe:1~25Hz

LED refresh rate:900Hz~25K Hz

Color wheel:7 + 1

H2O effect:1 pcs

CONTROL & PROGRAM

Channel:5 CH

Protocal:DMX512, RDM

Power input/output: Waterproof gland with cable + KST connector

Display: OLED display

SOFTWARE

Via DMX signal to update

Intelligent temperature protection to ensure LED service life

HOUSING

Aluminum alloy structure

Natural heat dissipation

Resistant to salt corrosion


OTHER

IP rating:IP65

Work environment:-40℃—45℃

Startup environment:-20℃—45℃

POWER CONSUMPTION

Voltage:AC 100V-240V 50/60HZ

Rated power:240W

SIZE & WEIGHT

Size:286× 300 × 208 mm

N.W:6.1 kgs

Carton Size:410×360×600 mm

G.W:16 kgs  (2PCS)


Photometrics

IP H2O 200 照度.jpg

Dimensions
